Fluorescent Yellow Powder for “Ready to use suspension form”, in oil, for Inspection under UVA light .for crack detection by Magnetic Particle Inspection Method.
Technical Details:
- • Colour in day light: Green
- • Colour under UVA Light: Fluorescent
- • Aerosol Can Volume: 500ml
- • Net Content: 420ml (Product + Propellant)
- • Weight: 417gm ( approximate) per can
- • Standard Packing: 24Aerosol Cans in corrugated Box
Features:
- • Chemical Nature: Non hazardous, Non-Toxic, Non-Corrosive Liquid.
- • Shelf Life: The product will be suitable for its designated use till two (2) years from the date of manufacture, if store dwell , and in packed condition as supplied.
- • Sensitivity on Keto’s Tool Steel Ring, as per ASTM E 1444 TableNo.X1.2, for 1400 Amp HWDC: Number of holes indicated is 6.( Required : 3 holes minimum)
Compliance Standard:
- • ASTME-709: Standard Guide For Magnetic Particle Testing
- • ASTME-1444: Standard Practice For Magnetic Particle Testing
Desirable Recommendations:
- • Ensure that the testing premises are well ventilated.
- • Component surface should be pre – cleaned and free from oil / grease etc. at the time of use.
- • The In section should be carried out in dark conditions (white light inside the dark area should be less than 20 Lux strength ) with help of UVA Light of minimum intensity 1000 micro watt / sq. cm. at 15 inches from source.
For Storage:
- • Store in Dry, Cool, Shaded Area and at temperature less than 50ºC.
- • Always store can vertically.
Safety:
- Please note that propellant used is a flammable gas, also the solvent used is highly evaporating and flammable. Necessary precautions, such as keeping the surrounding atmosphere free of flame or sparks is essential.
